Product BL20-1CNT-24VDC
BL20 electronic module
Counter
Order number: 6827031- Fieldbus and connection technology independent
- Protection class IP20
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- Detection of standard counting signals
- 1 digital input, 24 VDC
- 1 digital output, 24 VDC, 2A
- Counting mode: Continuous, single or periodic count
- Measuring mode: Frequency, rotational speed or period duration measurement
General data
| EAN | 4047101137743 |
| eCl@ss-Code (V5.1.4): | 27250307 -/- Technology module (periphery) |
| Customs tariff number | 85389091890 |
| Country of origin | DE |
| Weight | 41 g |
Technical Data
| Signal type | Counter, Digital input |
| Connection technology signal | Screw terminal, Cage clamp terminal |
| Device type | I/O Module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
| Approvals | cULus |
Data Sheets
| German | 206 KB |
| English | 206 KB |
| French | 207 KB |
| Spanish | 207 KB |
| Czech | 208 KB |
| Dutch | 206 KB |
| Romanian | 207 KB |
| Russian | 221 KB |
| Polish | 208 KB |
| Turkish | 208 KB |
Approval
| FM07 ATEX 0040X | 739 KB |
| IECEx FME 07.0004X | 251 KB |
| FM Class 1 Div. 2 US | 178 KB |
| FM Class 1 Div. 2 Canada | 179 KB |
| EU Declaration of Conformity | 136 KB |
