Product BL20-PF-120/230VAC-D
BL20 electronic module
Power Feeding Module with Diagnostics Function
Order number: 6827008- Fieldbus and connection technology independent
- Protection class IP20
- LEDs indicating system status, field supply and diagnostic information
- Can be used to form potential groups
- Supplies field with 120/230 VAC nominal voltage
General data
| EAN | 4047101137521 |
| eCl@ss-Code (V5.1.4): | 27250311 -/- Power supply (decentralized periphery) |
| Customs tariff number | 85389091890 |
| Country of origin | DE |
| Weight | 36 g |
Technical Data
| Signal type | Power supply |
| Connection technology signal | Screw terminal, Cage clamp terminal |
| Device type | I/O Module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
| Approvals | cULus |
