Product FD-48-T317/EX
PROFIBUS-PA
Fieldbus Display, 3-channel
Order number: 6901315- Digital fieldbus display for the indication of process values
- Powder-coated die-cast aluminium housing
- Connection of the housing potential via external earthing
- Entity and FISCO compliant according to IEC TS 60079-27
General data
| eCl@ss-Code (V5.1.4): | 27250201 -/- Network components (fieldbus) |
| Customs tariff number | 85369095000 |
| Country of origin | DE |
| Weight | 1047 g |
Technical Data
| Network protocol | PROFIBUS-PA |
| Connection technology signal | Cable gland |
| Device type | Fieldbus display |
| Ambient temperature | -10…+60 °C |
| Protection class | IP66 |
| Approvals | ATEX |
