Product SNNE-0008D-0006
piconet Extension Module for IP-Link
8 Digital Outputs 0.5 A
Order number: 6824185- Direct connection to the IP link
- Fibre-glass reinforced housing
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101179101 |
| eCl@ss-Code (V5.1.4): | 27250302 -/- Digital I/O module (periphery) |
| Customs tariff number | 85176200000 |
| Country of origin | DE |
| Weight | 175 g |
Technical Data
| Network protocol | PROFIBUS-DP, DeviceNet, CANopen, Modbus TCP, EtherNet/IP, PROFINET |
| Signal type | Digital output |
| Connection technology signal | M8 |
| Device type | Extension module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP67 |
| Approvals | cULus |
