Product  TBEN-LL-4RMC-4DIP-4DXP

Compact PROFINET I/O Module

4 Roller Motor Controllers

4 digital PNP inputs, 4 universal digital channels, configurable as PNP inputs or 2A outputs

Order number: 100018352
#

General data

EAN 4047101524055
eCl@ss-Code (V5.1.4): 27250302 -/- Digital I/O module (periphery)
Customs tariff number 85389099990
Country of origin DE
Weight 573 g

Technical Data

Network protocol Modbus TCP, EtherNet/IP, PROFINET
Signal type Roller motor, Digital input, Digital input/output, Digital input
Connection technology signal M12
Product series TBEN-L
Device type I/O Module, Compact station, Field Logic Controller (ARGEE)
Protection class IP65/IP67/IP69K
Ambient temperature -40…+70 °C

Connectivity accessories — Power supply

RKP56PLB-2-RSP56PLB/TXG Extension cable, M12 female, straight, 4-pin + FE, L-coded; M12 male connector, straight, 4-pin + FE, L-coded; cable length: 2 m, jacket material: PUR, gray; other cable lengths and qualities available, see www.turck.com
RSP56PLB-2/TXG Connection cable, M12 male connector, straight, 5-pin, cable length: 2 m, sheathing material: PUR, gray; other cable lengths and qualities available, see www.turck.com
RKP56PLB-2/TXG Connection cable, M12 female connector, straight, 5-pin, cable length: 2 m, jacket material: PUR, gray; other cable lengths and qualities available, see www.turck.com

Connectivity accessories — I/O

RKC4T-2-RSC4T/TXL Extension cable, M12 female, straight, 3-pin to M12 male, straight, 3-pin; cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
WKC4T-2-RSC4T/TXL Extension cable; M12 female, angled, 3-pin to M12 male, straight, 3-pin; cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
RKC4.4T-2-RSC4.4T/TXL Extension cable, M12 female, straight, 4-pin to M12 male, straight, 4-pin; cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
WKC4.4T-2-RSC4.4T/TXL Extension cable, M12 female, angled, 4-pin to M12 male, straight, 4-pin, cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
WKC4.5T-2-RSC4.5T/TXL Extension cable, M12 female, angled, 5-pin to M12 male, straight, 5-pin; cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
RKC4.5T-2-RSC4.5T/TXL Extension cable, M12 female, straight, 5-pin to M12 male, straight, 5-pin; cable length: 2 m, jacket material: PUR, black; cULus approval; other cable lengths and qualities available, see www.turck.com
VBRS4.4-2RKC4T-1/1/TXL 2-port junction systems — Y-splitter with cable, M12 male connector, straight, 4-pin — 2 × M12 female connector, straight, 3-pin, cable length: 1 m, jacket material: PUR, black; other cable lengths and qualities available, see www.turck.com

Connectivity accessories — Network

RSSD-RJ45S-4416-2M Cable for Industrial Ethernet, M12 connector, straight to RJ45 connector, straight, cable length: 2 m, jacket material: PUR, green; other cable lengths and qualities available, see www.turck.com
RSSD-RSSD-4416-2M Cable for Industrial Ethernet, M12 connector, straight to M12 connector, straight, cable length: 2 m, jacket material: PUR, green; other cable lengths and qualities available, see www.turck.com
