Product SNNE-40A-0004
piconet Extension Module for IP-Link
4 Analog Inputs for Thermoelements
Order number: 6824215- 4 analog inputs for thermoelements
- Direct connection to the IP link
- Fibre-glass reinforced housing
- Encapsulated module electronics
- Metal connector
- Degree of protection IP67
General data
| EAN | 4047101179408 |
| eCl@ss-Code (V5.1.4): | 27250303 -/- Analog I/O module |
| Customs tariff number | 85176200000 |
| Country of origin | DE |
| Weight | 181 g |
Technical Data
| Network protocol | PROFIBUS-DP, DeviceNet, CANopen, Modbus TCP, EtherNet/IP, PROFINET |
| Signal type | Analog input |
| Connection technology signal | M12 |
| Device type | Extension module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP67 |
| Approvals | cULus |
Connectivity accessories — I/O
|
WAS5-THERMO
Compensating connector with Pt1000 for TBEN-S2-4AI operating mode thermocouple |
6824260 |
