Product BL20-4AI-U/I
BL20 electronic module
4 Analog Inputs
Order number: 6827217- Fieldbus and connection technology independent
- Protection class IP20
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- 4 analog inputs
- 0/4 … 20 mA or 10/0 … +10 VDC
- Selectable per channel
General data
| EAN | 4047101137828 |
| eCl@ss-Code (V5.1.4): | 27250303 -/- Analog I/O module |
| Customs tariff number | 85389091890 |
| Country of origin | DE |
| Weight | 37 g |
Technical Data
| Signal type | Analog input |
| Connection technology signal | Screw terminal, Cage clamp terminal |
| Device type | I/O Module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
| Approvals | cULus |
Data Sheets
| German | 362 KB |
| English | 359 KB |
| French | 360 KB |
| Spanish | 360 KB |
| Czech | 361 KB |
| Dutch | 359 KB |
| Romanian | 360 KB |
| Russian | 374 KB |
| Polish | 361 KB |
| Chinese | 401 KB |
| Turkish | 361 KB |
Approval
| FM07 ATEX 0040X | 739 KB |
| IECEx FME 07.0004X | 251 KB |
| FM Class 1 Div. 2 US | 178 KB |
| FM Class 1 Div. 2 Canada | 179 KB |
| EU Declaration of Conformity | 136 KB |
