Product ESHP4P
M8 x 1 / Ø 8 mm round connector
Ø 8 mm Flange Connector, Snap-on Type
Order number: 6934774- Robust and pre-assembled flange connector
- 4-pin
- Potted, protection class IP67
- GOST-R-approved
- RoHS-compliant
- Print contact
General data
| EAN | 4047101371390 |
| eCl@ss-Code (V5.1.4): | 27250107 -/- Connection cable sensor-actuator |
| Customs tariff number | 85366990990 |
| Country of origin | DE |
| Weight | 1 g |
Technical Data
| Application | Signal |
| Connector A | Male, Ø 8 mm |
| Number of pins | 4 |
| Flange housing | Brass, CuZn, Nickel-plated |
| Flange housing | Brass, CuZn, Nickel-plated |
| Voltage | 30 V |
| Current | 4 A |
| Protection class | IP67 |
