Product  BIM-EM12E-Y1X

Magnetic Field Sensor

Magnetic-inductive Proximity Sensor

Order number: 1070036
    • Threaded barrel, M12 x 1
    • Stainless steel, 1.4301
    • Rated operating distance 90 mm with DMR31-15-5 magnet
    • DC 2-wire, nom. 8.2 VDC
    • Output acc. to DIN EN 60947-5-6 (NAMUR)
    • Cable connection
#

General data

EAN 4047101064568
eCl@ss-Code (V5.1.4): 27270104 -/- Magnetic inductive proximity switch
Customs tariff number 85365019900
Country of origin DE
Weight 116 g

Technical Data

Design Threaded barrel
Construction size M12 x 1
Rated switching distance 90 mm
Output function NAMUR
Electrical connection Cable
Cable length 2.0  m
Housing material Stainless steel, 1.4301 (AISI 304)
Ambient temperature -25…+70 °C
Protection class IP67
Approvals ATEX II 1G, ATEX II 2G, ATEX II 3G, ATEX II 1D, ATEX II 2D, ATEX II 3D, SIL2, PLc
Special features Magnetic-inductive
