Product  RKC4T-2/TEL

Actuator and Sensor Cable, PVC

Connection Cable

Order number: 6625010
    • Female M12, straight, 3-pin
    • Jacket material: PVC
    • Jacket color: black
    • Resistant to chemicals and oils
    • Flame-retardant
    • Resistant to acids and alkaline solutions
    • Resistant to microbes and hydrolysis
    • LABS free
    • Approval: cULus
    • RoHS-compliant
    • Protection class: IP67, IP69K
    • Cable length: 2.0 m
#

General data

EAN 4047101268676
eCl@ss-Code (V5.1.4): 27250107 -/- Connection cable sensor-actuator
Customs tariff number 85444290900
Country of origin PL
Weight 77 g

Technical Data

Application Sensor/Actuator connection
Connector A M12 × 1
Number of Conductors 3
Connector A - Number of Pins 3
Connector A - Style Straight, Female
Material coupling/housing A Brass
Voltage 250 V
Current 4 A
Cable quality PVC
Color cable Black
Cable length 2.0  m
