Product BC20-K40WDTC-VP4X2/S930
Capacitive Sensor
For the Food Industry
Order number: 2510105- 2 cable entries (axial, radial)
- Plastic LV-30H FWA
- Smooth barrel, Ø 40 mm
- High protection class IP69K, for harsh environments
- Special double-lip seal
- Protection against all common acid and alkaline cleaning agents
- Laser engraved label, permanently legible
- For the food industry
- Fine adjustment via potentiometer
- DC 4-wire, 10…65 VDC
- Complementary contact, PNP output
- Terminal chamber
General data
| EAN | 4047101259896 |
| eCl@ss-Code (V5.1.4): | 27270102 -/- Capacitive proximity switch |
| Customs tariff number | 85365080900 |
| Country of origin | DE |
| Weight | 172 g |
Technical Data
| Design | Smooth barrel |
| Construction size | Ø 40 mm |
| Rated switching distance | 30 mm |
| Output function | Complementary contact, PNP |
| Electrical connection | Terminal chamber, Removable cage clamp terminals |
| Housing material | Plastic, Grilamid LV-30H FWA |
| Ambient temperature | -25…+70 °C |
| Protection class | IP69K |
